Product Features

Equipped with various optoelectronic detection payloads such as infrared, laser, and millimeter-wave radar.

Combined with image recognition from the infrared detector, it enables automatic identification and tracking of weak and small infrared targets.

The platform adopts direct-drive motor technology, with the control part being a self-developed integrated servo control system, and all components are domestically produced.

Paired with mature stabilization and tracking algorithms, it offers high tracking accuracy and excellent dynamic performance. It has currently achieved mass production.

Performance Specifications

Material: Hard aluminum, steel

Dimensions: 900mm × 440mm × 990mm (Length × Width × Height)

Load Capacity: 75kg

Angular Position Measurement Accuracy: ≤10″

Tracking Accuracy: ≤0.1mrad (1σ, image tracking frame rate of 100Hz)

Tracking Angular Velocity with Maintained Accuracy: ≥25°/s

Temperature Range: -40°C to 70°C, Humidity: ≤90%, no condensation or frost
